OIL PAN KIT,GM LS RETROFIT,67-69 F,BLACK

Description

BRAND NEW HOLLEY GM LS SWAP OIL CAST PAN KIT WITH ADDITIONAL FRONT CLEARANCE, BLACK FINISH, 6 QUART CAPACITY, 3.62″ MAXIMUM STROKE, REAR SUMP

GM LS SWAP OIL PAN – 1955-1987 GM/MUSCLE CAR/CLASSIC CAR/TRUCKS CARS REQUIRING MORE CLEARANCE AT THE FRONT HALF OF THE OIL PAN. GREAT FOR 1967-1969 CAMARO/FIREBIRD, 1968-1974 NOVA/APOLLO/VENTURA/OMEGA, 1982-1992 F-BODY, 1978-1987 G-BODY, AND 1964-1972 A-BODY APPLICATIONS.

THE DISTANCE BETWEEN THE OIL PICKUP AND THE BOTTOM OF THE PAN IS .378 INCHES. ALSO, THE DISTANCE BETWEEN PICKUP TUBE AND THE SIDE OF THE OIL PAN IS 0.136 INCHES. PROVIDES OE STYLE FITMENT – OE OIL FILTER MOUNTING, OE OIL COOLER PORT PROVISION, OE ENGINE NVH SUPPRESSION, OE FLANGE GASKET & SEALING, PROPER STRUCTURAL RIGIDITY & OE BELL-HOUSING ATTACHMENTS.

NOTE: MAXIMUM CRANKSHAFT STROKE = 3.62″, SUMP OIL CAPACITY – 5.7 QUARTS, TOTAL OIL CAPACITY WITH STOCK OIL FILTER – 6.2 QUARTS.

NOTE: REQUIRES USE OF HOLLEY 302-15 DIPSTICK AND TUBE KIT OR LS3 DIPSTICK (GM PART #12669528) & TUBE (GM PART #12625031). ADDITIONAL PARTS NEEDED (OIL PAN GASKET 6665G OR GM 12612350, HIGH QUALITY RTV SEALER, OIL FILTER (AC DELCO PF48 OR PF48E, MOBILE M1-113, WIX 57060, HP-1017, OR EQUIVALENT)

NOTE: ENGINE LOCATION MAY NEED TO BE ADJUSTED (UP / DOWN OR FORE / AFT) FOR CROSS MEMBER OR STEERING LINKAGE CLEARANCE DEPENDING ON VEHICLE, STEERING CONFIGURATION & CHASSIS TYPE.

NOTE: DESIGNED TO BE COMPATIBLE WITH GM F-BODY WINDAGE TRAY, GM PART #12558253. A MODIFICATION TO THE WINDAGE TRAY IS REQUIRED TO PROVIDE CLEARANCE TO THE PICK-UP TUBE. A FULL-LENGTH WINDAGE TRAY MAY BE USED IF THE FRONT QUARTER OF THE TRAY IS REMOVED. SEE THE INSTRUCTION SHEETS SHOWING THE WINDAGE TRAY MODIFICATIONS AND LENGTHS REQUIRED.

FEATURES:

• DESIGNED TO BE COMPATIBLE WITH LS ENGINE SWAP INSTALLATIONS IN GM MUSCLE/CLASSIC CAR & TRUCK CHASSIS REQUIRING MORE OIL PAN TO CHASSIS CLEARANCE AROUND THE FRONT HALF OF THE OIL PAN
• CAN BE USED ANYWHERE A GM F-BODY OIL PAN CAN BE USED
• HIGH-QUALITY CAST ALUMINUM WITH BLACK FINISH
• PROVIDES MAX CLEARANCE FOR VEHICLES WHERE STEERING LINKAGE IS BEHIND ENGINE CROSSMEMBER
• INCLUDES SUMP BAFFLE, OE STYLE PICK-UP TUBE, SUMP PLUG, OIL FILTER STUD, OIL PASSAGE COVER

SPECS:

• APPLICATION: GM LS ENGINES
• FINISH: BLACK CAST
• MATERIAL: ALUMINUM
• MAXIMUM STROKE: 3.62″
• OIL PAN CAPACITY: 6.0 QUARTS
• PRODUCT TYPE: OIL PAN KIT
• SUMP LOCATION: REAR
• TURBO OIL DRAINBACK: NO

YOU CAN VIEW AND DOWNLOAD THE COMPLETE ASSEMBLY INSTRUCTION BOOKLETS FOR THIS OIL PAN HERE.
